Characteristics
Family
Platform trailers
Total weight
3500 kg
Number of axles
2
Robust, a safe investment and extremely practical for loading heavy or bulky items. With its low loading height of 670 mm with 13" tyres, these high-bed models are the first choice for safe transport. The low loading angle ensures maximum convenience without any fuss and manoeuvring for fast loading and unloading. This is appreciated by professionals from the trade, craft and industrial sectors for whom smooth operations are especially important during work and transport. In addition you can naturally depend on the customary Böckmann quality for maximum durability and a safe investment.
Maximum flexibility - For high-bed trailers and tipping trailersUniform side walls
Maximum flexibility - For high-bed trailers and tipping trailersExtensive range of accessories
Stable construction
Comfort and handling
Accessories
Technical data
Base
Middle post
Jockey wheel
Automatic
Tires
13.0 Zoll
Swinging rear flap
Loading height
670 mm
Overrun brake
Weight
Total weight
3500 kg
Payload
2753 kg
External dimensions
Total length
5775 mm
Total width
2165 mm
Total height
1020 mm
Internal dimensions
Interior length
4140 mm
Interior width
2100 mm
Interior height
350 mm
Standard features
Body
-
Side walls
- sidewalls alu-anodized;corner rungs removable,catches on the inside
- Lashings
Chassis
-
Chassis
- self-supporting drawbar 1550mm
- Jockey wheel
Accessories
Body
-
Side walls
- Selection sidewall extension
- sidewall height extended to 500 mm
- Selection side wall / locking devices
- sidewalls alu, corner posts removable, angle lever lock
- price reduction without side walls
- Optional side wall covering
- side walls inside with sheet steel cover
-
Attachments
- Selection side wall gallery
- sidewall gallery
- Selection attachments
- climbing aid
- spare wheel 13"(195/50R13)
- Spare wheel holder, mounted on front profile
- Spare wheel holder, mounted under the floor
- storage case (plastic)
- ladder rack (front wall)
- telescopic crank drop legs (per pair)
-
Attachments
- steel sheet attachment 600 mm, 3-sides swivelling
- grass rails 1000 mm, 3-sided oscillating
- grass rails 600 mm, 3-sided oscillating
- box attachment (alu) 350 mm, 3-sided oscillating
- box attachment (alu) 500 mm, 3-sided oscillating
- box attachment (alu), 350 mm
-
Floor
- aluminium checker plate flooring
- galvanized steel sheet on floor (sheet shared)
-
Tarpaulin and hoops
- Options for hoops (for version with tarpaulin and hoop)
- canvas and frame with sales flap, one side to be posted
- Additional equipment for tarpaulins
- tarpaulin and hoop mounted
- tarpaulin labelling, exclusive marking, 2 sides
- advertisement on canvas , exclusive marking, 3 sides
- advertisement on canvas , exclusive marking, 4 sides
- tarpaulin labelling, standard marking, 2 sides
- tarpaulin labelling, standard marking, 3 sides
- tarpaulin lettering, standard marking, 4 sides
- tarpaulin labelling, full marking, 2 sides
- tarpaulin labelling, full marking, 3 sides
- tarpaulin labelling, full marking, 4 sides
- sliding canvas, without middle post, per side
- Selection tarpaulin and hoop (not mounted)
- flat tarpaulin with corner cut-outs
- frame and PVC canvas, 1500 mm
- frame and PVC canvas, 1700 mm
- frame and PVC canvas, 1900 mm
- Selection colour of tarpaulin
- canvas colour: blue (similar to RAL5010)
- canvas colour: yellow (similar to RAL1021)
- canvas colour: green (similar to RAL6026)
- canvas colour: orange (similar to RAL2011)
- canvas colour: red (similar to RAL3002)
- canvas colour: black (similar to RAL9005)
- canvas colour: white (similar to RAL9016)
- canvas colour: grey (similar to RAL7035)
-
Loading
- Selection loading
- container net including 32 flexible net hooks
- Selection retractable drive-on rails
- alum. loading rails, 2370x310mm, supp. cap. 2000 kg/per pair
- alum. loading rails, 2370x310mm, supp. cap. 2700 kg/per pair
-
Lashings
- C-rail, integrated in floor, crosswise, per unit
- countersunk lashing ring
- additional lashing ring
- Special accessories
Other
-
Special accessories
- 24-volt lighting system (with 15-pin plug)
Chassis
-
Chassis
- Version drawbar
- V-drawbar extended up to 1750mm
- V-drawbar extended up to 2000mm
- height-adjustable overrun-device w/ ball coupling, DIN eye Ø40mm loose
- Selection chassis
- wheel shock absorbers (4 pcs)
- Jockey wheel
